Coilmatik 280
Single Head Coiler For Insulated Single Wires
- Working Range : 0.75 - 6 mm² insulated single wires
- Single winding head
- Up to 4 coils per minute
- ± % 0.15 length tolerance
- 1000 mm and 1250 mm double flyer payoff
- Variable coil outer diameter and height
- Siemens SIMOTION control system
Configuration
- A - COILMATIK 280 Coiling Unit
- B - DF1250 Double Flyer Payoff
- C - SH400 Shrinking Unit
Optional Equipment
- D - Coil Grouping & Strapping Unit
- E - Coil Palletizer
- F - Empty Pallet Magazine
- G - Pallet Stretching Unit
Coil Dimension
Cable Type
- Rigid or multi stranded single wire from 1,5 mm² up to 6 mm²
- Flexible single wire from 0,75 mm² up to 6 mm²
